I’ve created a custom stencil for ease of use, featuring LED, Tungsten, HMI, DMX, Electra, and various modifiers to streamline your design process. If you have any suggestions or additional elements you’d like to see included, let me know—I’ll happily add them free of charge!

Lighting Plot

A lighting plot is a detailed visual plan used in theater, film, or live events to map out the placement, type, and direction of lighting instruments. It serves as a blueprint for the lighting designer and technical team, ensuring that all lights are positioned and focused correctly to create the desired effects.

Typically, a lighting plot includes a top-down view of the stage or performance area, with symbols representing different lighting fixtures. It may also note the intensity, color gels, gobos (patterned filters), and angles for each light. Alongside the plot, a cue sheet often details when and how lights should change during the production.

By carefully planning a lighting plot, designers can shape the atmosphere, highlight key moments, and guide the audience’s focus effectively. It’s an essential tool for seamless coordination between artistic vision and technical execution.

Omnigraffle Stencil

To import an OmniGraffle stencil, follow these simple steps:

1. Download the Stencil: Locate and download the stencil file (usually with the extension .gstencil) from a trusted source.
2. Open OmniGraffle: Launch OmniGraffle on your device.
3. Import the Stencil:
   • Drag the downloaded .gstencil file directly into the Stencil Browser (accessible from the Sidebar or via View > Show Stencils).
   • Alternatively, double-click the .gstencil file, and it will open in OmniGraffle, ready for use.
4. Access the Stencil: The stencil will now appear in your Stencil Browser under the category it belongs to. You can start dragging items from the stencil onto your canvas.

That’s it—your stencil is imported and ready to streamline your design process!

Download Omnigraffle Here
